ComNet 8-Channel Optically Isolated Contact Closure Transmitter - 1 x ST Ports - Multi-mode - 16.09 km - Power Supply - DIN Rail Mountable

The ComNet™ FDC8ISOT 8-Channel Contact Closure Transmitter unit provides up to eight independent normally-open (NO) dry contact closures over one multimode or single-mode optical fiber, when used in conjunction with the companion ComNet model FDC8NLR Non-Latching Receiver or FDC8R Latching Receiver units. Each of the contact closure inputs are optically isolated at 1500V to ground, for those applications where high stray or transient voltages may exist. Microprocessor-based logic in the FDC8ISOT Transmitter detects a customer-furnished switch or contact closure, and encodes the closure into robust data packets that are mapped and transmitted to the FDC8NLR Receiver. Packets received with excessive bit errors will not result in random changes in the receiver relay contact resting or actuated states, making this system ideal for mission critical remote switching applications. Plug-and-play design ensures ease of installation and operation, and no optical or electrical adjustments are ever required.

Availability: Call or email

$1,430.38
$1,430.38

Fast shipping on all in-stock products

Quick turnaround on RFQs - email us today.

Buy from a certified veteran-owned small business (VOSB)

Questions? Call customer service at 503-208-8410.

Description

Details

ComNet 8-Channel Optically Isolated Contact Closure Transmitter - 1 x ST Ports - Multi-mode - 16.09 km - Power Supply - DIN Rail Mountable

OVERVIEW:

  • Power Source : Power Supply
  • Package Contents :
    • 8-Channel Optically Isolated Contact Closure Transmitter
    • DC Plug-in Power Supply, 90-264 VAC, 50/60 Hz
  • Media Type Supported : Optical Fiber
  • Total Number of Ports : 1
  • Limited Warranty : Lifetime
  • Power Consumption : 3 W
  • Form Factor : DIN Rail Mountable
  • Fiber Mode Supported : Multi-mode
  • Plug/Connector Type : Terminal Block
  • Height : 5.3"
  • Environmentally Friendly : Yes
  • Width : 6.1"
  • Depth : 1.1"
  • Maximum Distance Supported : 16.09 km
  • Environmental Compliance : Waste Electrical and Electronic Equipment Directive (WEEE)
  • Environmental Compliance : Restriction of Hazardous Substances (RoHS)
  • Fiber Optic Cable Core/Cladding Specification : 62.5/125 µm
  • Country of Origin : United States
  • Number of ST Ports : 1
  • Additional Info

    Additional Info

    SKU 04938FDC8NLRM1-BF
    Weight 1.0000
    Is Featured N/A
    Manufacturer ACRE
    Manufacturer Part Number FDC8NLRM1
    Width 6.1"
    Length 1
    Height 5.3"
    Product ID 04938FDC8NLRM1
    UNSPSC N/A
    Other Part Number N/A
    Special Price N/A
