Advantech AIMB-582 Desktop Motherboard - Intel Q77 Express Chipset - Micro ATX - 32 GB DDR3 SDRAM Maximum RAM - DIMM - 4 x Memory Slots - Gigabit Ethernet - DisplayPort - 6 x SATA Interfaces

Availability: Call or email

Regular Price: $509.99

Special Price $479.39

Regular Price: $509.99

Special Price $479.39

Qty:

Description

Details

Advantech AIMB-582 Desktop Motherboard - Intel Q77 Express Chipset - Micro ATX - 32 GB DDR3 SDRAM Maximum RAM - DIMM - 4 x Memory Slots - Gigabit Ethernet - DisplayPort - 6 x SATA Interfaces

OVERVIEW:

Number of SATA Interfaces : 6

Controller Type : Serial ATA/600

Limited Warranty : 2 Year

Onboard Video : CPU Dependent Video

Chipset Manufacturer : Intel

Package Contents :

AIMB-582 Desktop Motherboard
2 x SATA HDD Cable
2 x SATA Power Cable
1 x I/O Port Braket
1 x Startup Manual
1 x Driver CD

Number of Memory Slots : 4

Total Number of Expansion Slots : 4

Chipset Model : Q77 Express

Form Factor : Micro ATX

Memory Form Factor : DIMM

Total Number of PCI Express Slots : 2

Graphics Controller Model : HD Graphics

Total Processor Supported : 1

Gigabit Ethernet : Yes

Energy Star : Yes

Maximum Memory Supported : 32 GB

Total Number of USB Ports : 4

Width : 9.6"

Environmentally Friendly : Yes

Memory Speed Supported : 1600 MHz

Memory Speed Supported : 1333 MHz

Number of PCI Express x4 Slots : 1

RAID Supported : Yes

Depth : 9.6"

Number of USB 3.0 Ports : 4

RAID Levels : 10

RAID Levels : 5

RAID Levels : 1

RAID Levels : 0

Processor Supported : Celeron

Processor Supported : Pentium

Processor Supported : Core i3

Processor Supported : Core i5

Processor Supported : Core i7

Weight (Approximate) : 2.65 lb

Memory Technology : DDR3 SDRAM

Number of PCI Express x16 Slots : 1

Total Number of Onboard USB Ports : 8

Environmental Compliance : Waste Electrical and Electronic Equipment Directive (WEEE)

Environmental Compliance : Restriction of Hazardous Substances (RoHS)

Number of Onboard USB 2.0 Ports : 8

Country of Origin : NA

VGA : Yes

DisplayPort : Yes

DVI : Yes

Number of Network (RJ-45) Ports : 2

Additional Info

SKU	01074AIMB582QG2TPA1E-BF
Weight	2.6500
Is Featured	N/A
Manufacturer	Advantech Co., Ltd
Manufacturer Part Number	AIMB-582QG2-TPA1E
Width	9.6"
Length	1
Height	1
Product ID	01074AIMB582QG2TPA1E
UNSPSC	N/A
Other Part Number	N/A
Special Price	N/A

Advantech AIMB-582 Desktop Motherboard - Intel Q77 Express Chipset - Micro ATX - 32 GB DDR3 SDRAM Maximum RAM - DIMM - 4 x Memory Slots - Gigabit Ethernet - DisplayPort - 6 x SATA Interfaces
