APC by Schneider Electric Symmetra PX 100000VA Modular UPS - Modular - 3.50 Hour Recharge - 480 V AC, 415 V AC, 400 V AC Input - 415 V AC, 400 V AC, 480 V AC Output - 1 x Hard Wire 4-wire (3PH + G), 1 x Hard Wire 5-wire (3PH + N + G) - Sine Wave - LCD Display
OVERVIEW:
Limited Warranty : 1 YearLoad Capacity (VA) : 100 kVAPackage Contents : - Symmetra PX 100000VA Modular UPS
- Assembly Service
- Network Management Card
- Start-Up Service
- User Manual
Network Management : ModbusNetwork Management : Network Management Card 2Display : LCDAdditional Warranty Information : 1 year on-site repair or replace with factory authorized Start-Up
Load Capacity (Watt) : 100 kWForm Factor : ModularMaximum Operating Temperature : 104°F (40°C)Plug/Connector Type : Hard Wire 5-wire (3PH + N + G)Plug/Connector Type : Hard Wire 4-wire (3PH + G)USB : NoBattery Characteristics : Valve-regulatedReceptacle Type : Hard Wire 5-wire (3PH + N + G)Receptacle Type : Hard Wire 4-wire (3PH + G)Input Voltage : 400 V ACInput Voltage : 415 V ACInput Voltage : 480 V ACHeight : 78.4"Maximum Operating Elevation : 3333 ftBattery Chemistry : Lead AcidReceptacle Detail : 1 x Hard Wire 5-wire (3PH + N + G)Receptacle Detail : 1 x Hard Wire 4-wire (3PH + G)Input Voltage Range : 340 V AC - 460 V ACInput Voltage Range : 408 V AC - 552 V ACWidth : 92.5"Maximum Storage Elevation : 50000 ftOutput Voltage : 480 V ACOutput Voltage : 400 V ACOutput Voltage : 415 V ACDepth : 42.1"Input Frequency : 70 HzInput Frequency : 40 HzWeight (Approximate) : 5804.18 lbStorage Relative Humidity : 0% - 95%Battery Energy : 130636.8 kJOutput Frequency : 60 HzOutput Frequency : 50 HzWaveform Type : Sine WaveSound Emission (A-Weighted) : 54 dB(A)Transfer Time : 2 msThermal Dissipation : 3627.63 WInput Power Factor : 0.99Output Power Factor : 1Typical Battery Recharge Time : 3.50 HourPhase : Three PhaseApplication/Usage : ServerApplication/Usage : Mission Critical EquipmentApplication/Usage : Data CenterEfficiency : 96.5%
