Eaton 850VA 510W 120V AC DIN Rail Industrial UPS - Hardwire Input/Output - 12 x NEMA 5-15R - 3U 19" Rack-mountable

Flexible Power Protection for Smart Industrial Applications

The DIN850AC standby UPS system with hardwire AC input/output delivers reliable power and battery backup for computing, networking, control and storage equipment in factories, warehouses, edge computing locations and automated manufacturing and fabrication facilities. The rugged compact housing withstands demanding conditions and integrates seamlessly and securely into electrical enclosures in any non-traditional IT environment.

Ideal for Factory Floors and Extreme Temperatures

Get full use of the DIN850AC's power capacity because there is no derating based on its operating temperature range of 0°C (32°F) to 50°C (122°F), which expands the number of locations in which it can be used. Built to fit into small spaces, the DIN850AC is a UL 508 recognized component for use in industrial panels. Its pre-installed clamp enables quick mounting to a 35 mm DIN rail. Its fanless design reduces noise and increases reliability.

Reliable Battery Backup Keeps You Operational Through Power Outages

Power outages not only drain productivity from the factory floor, but they also damage expensive equipment. The DIN850AC protects productivity by providing enough runtime to maintain operation during a brief power outage and protects equipment by allowing it to complete an operation during an extended outage. It also prevents brownouts, overvoltages, surges and line noise from damaging equipment that could destroy data and contribute to costly downtime.

Convenient Automatic Restart

The DIN850AC automatically restarts when AC power is restored after an outage, eliminating the need for a costly site visit.

Stay in Control of Your Operation

LEDs on the front panel confirm normal operation and indicate alarm or fault status. Remote on/off and a battery indicator mode can help you avoid maintenance surprises. The DIN850AC is compatible with PowerAlert® Office software for UPS monitoring and control via USB connection.

Easy Preventative Maintenance and Initial Troubleshooting

The DIN850AC's self-test capability and user-replaceable internal battery can extend the life of the UPS and minimize disruption to operations. A resettable circuit breaker helps prevent dangerous system overloads.

Availability: Call or email

$875.00
$875.00
Eaton Corporation

Fast shipping on all in-stock products

Quick turnaround on RFQs - email us today.

Buy from a certified veteran-owned small business (VOSB)

Questions? Call customer service at 503-208-8410.

Description

Details

Eaton 850VA 510W 120V AC DIN Rail Industrial UPS - Hardwire Input/Output - 12 x NEMA 5-15R - 3U 19" Rack-mountable

OVERVIEW:

  • Limited Warranty : 2 Year
  • Load Capacity (VA) : 850 VA
  • Package Contents :
    • DIN850AC 850VA DIN Rail UPS
    • USB Communication Cable
    • Safety Card
    • Owner's Manual
  • Display : LED
  • Status Indicators :

    LED Indicators:

    • ALARM - RED - Flashes when the battery needs to be recharged and tested.
    • SOLID RED when the unit is subjected to an overload condition.
    • YELLOW - ON SOLID when the UPS is supplying battery power to the loads.
    • GREEN - ON SOLID GREEN when the line input voltage is normal.
  • DC System Voltage : 12 V DC
  • Load Capacity (Watt) : 510 W
  • Height : 5.2"
  • Maximum Operating Elevation : 9843 ft
  • Plug/Connector Type : Hardwired
  • Width : 12.2"
  • Battery Characteristics : Valve-regulated
  • Receptacle Type : Hardwired
  • Input Voltage : 120 V AC
  • Depth : 5.5"
  • Storage Temperature : 5°F (-15°C) - 122°F (50°C)
  • EPO Port : Yes
  • Battery Chemistry : Lead Acid
  • Receptacle Detail : 1 x Hardwired
  • USB (HID Compliant) Port : Yes
  • Output Voltage : 120 V AC
  • Form Factor : DIN Rail
  • Environmentally Friendly : Yes
  • Weight (Approximate) : 12.10 lb
  • Maximum Operating Temperature : 122°F (50°C)
  • Backup/Run Time (Full Load) : 2 Minute
  • Output Frequency : 60 Hz
  • Backup/Run Time (Half Load) : 7 Minute
  • Sound Emission (A-Weighted) : 40 dB(A)
  • Waveform Type : Pulse-width Modulated Sine Wave
  • Environmental Compliance : Restriction of Hazardous Substances (RoHS)
  • Thermal Dissipation : 15.27 W
  • Surge Energy Rating : 588 J
  • Transfer Time : 10 ms
  • EMI/RFI Noise Filter : Yes
  • Phase : Single Phase
  • Output Power Factor : 0.6
  • Application/Usage : Machine Control
  • Application/Usage : Industrial
  • Application/Usage : IT System
  • Application/Usage : Manufacturing Facility
  • Application/Usage : Automation Industry
  • Application/Usage : Factory
  • Application/Usage : Storage Device
  • Application/Usage : Network
  • Application/Usage : Edge Computing
  • Additional Info

    Additional Info

    SKU 01731DIN850AC-BF
    Weight 12.1000
    Is Featured N/A
    Manufacturer Eaton Corporation
    Manufacturer Part Number DIN850AC
    Width 12.2"
    Length 1
    Height 5.2"
    Product ID 01731DIN850AC
    UNSPSC N/A
    Other Part Number N/A
    Special Price N/A
