Server Technology Switched PDU - 7.3kW, C1W16HR-EPAA5BAC - Switched - IEC 2P+PE 6Hr 230V/32A - 16 x IEC 60320 C13 - 230 V AC - Network (RJ-45) - 2U - Rack-mountable

The Server Technology® PRO1 Switched PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO1 Switched "Master" PDU can be connected to as many as three (with optional module) PRO1 Switched "Link" PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration. The Server Technology® PRO1 Switched PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO1 Switched "Master" PDU can be connected to as many as three (with optional module) PRO1 Switched "Link" PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.

Availability: Call or email

$1,093.66
$1,093.66
Server Technology, Inc

Fast shipping on all in-stock products

Quick turnaround on RFQs - email us today.

Buy from a certified veteran-owned small business (VOSB)

Questions? Call customer service at 503-208-8410.

Description

Details

Server Technology Switched PDU - 7.3kW, C1W16HR-EPAA5BAC - Switched - IEC 2P+PE 6Hr 230V/32A - 16 x IEC 60320 C13 - 230 V AC - Network (RJ-45) - 2U - Rack-mountable

OVERVIEW:

  • Limited Warranty : 2 Year
  • PDU Type : Switched
  • Input Voltage : 230 V AC
  • Management :
    • SSH
    • SMTP
    • Syslog
    • HTTP/HTTPS
    • TLSv1.2
    • SSHv2
    • Telnet
    • SNMPv2c and v3 (GET, SET, Traps)
    • IPv4 and IPv6
    • LDAPv3/LDAPS
    • TACACS+
    • RADIUS
    • FTP/SFTP
  • Network (RJ-45) : Yes
  • Phase : Three Phase
  • Output Voltage : 230 V AC
  • Mount Type : Rack-mountable
  • Plug/Connector Type : IEC 2P+PE 6Hr 230V/32A
  • Country of Origin : United States
  • Receptacle Type : IEC 60320 C13
  • Rack Height : 2U
  • Environmentally Friendly : Yes
  • Receptacle Detail : 16 x IEC 60320 C13
  • Power Rating (Watt) : 7300 W
  • Input Current : 32 A
  • Height : 3.5"
  • Protection Type : Double Pole
  • Protection Type : Fuse
  • Width : 17.2"
  • Depth : 7.1"
  • Environmental Compliance : Waste Electrical and Electronic Equipment Directive (WEEE)
  • Environmental Compliance : Restriction of Hazardous Substances (RoHS)
  • Additional Info

    Additional Info

    SKU 03103C1W16HREPAA5BAC-BF
    Weight 1.0000
    Is Featured N/A
    Manufacturer Server Technology, Inc
    Manufacturer Part Number C1W16HR-EPAA5BAC
    Width 17.2"
    Length 1
    Height 3.5"
    Product ID 03103C1W16HREPAA5BAC
    UNSPSC N/A
    Other Part Number N/A
    Special Price N/A
