Server Technology PRO2 48-Outlets PDU - Switched - NEMA L22-30P - 48 x IEC 60320 C13 - 415 V AC - Branch Circuit, Circuit Protection, Circuit Breaker, Fuse - Network (RJ-45) - 0U - Rack-mountable, Button Mount

The Server Technology® PRO2 Switched PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS® technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO2 Switched "Primary" PDU can be connected to as many as three (with optional module) PRO2 Switched "Link" PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.

Availability: Call or email

Regular Price: $2,993.00

Special Price $2,813.42

Regular Price: $2,993.00

Special Price $2,813.42

Server Technology, Inc

Fast shipping on all in-stock products

Quick turnaround on RFQs - email us today.

Buy from a certified veteran-owned small business (VOSB)

Questions? Call customer service at 503-208-8410.

Description

Details

Server Technology PRO2 48-Outlets PDU - Switched - NEMA L22-30P - 48 x IEC 60320 C13 - 415 V AC - Branch Circuit, Circuit Protection, Circuit Breaker, Fuse - Network (RJ-45) - 0U - Rack-mountable, Button Mount

OVERVIEW:

  • Limited Warranty : 2 Year
  • PDU Type : Switched
  • Input Voltage : 415 V AC
  • Package Contents :
    • PRO2 48-Outlets PDU
    • Standard Button Mounts
  • Management :
    • HTTP/HTTPS
    • TLSv1.2
    • SSHv2
    • Telnet
    • SNMPv2c
    • SNMPv3 (GET, SET, Traps)
    • IPv4
    • IPv6
    • LDAPv3/LDAPS
    • TACACS+
    • RADIUS
    • FTP/SFTP
  • Minimum Operating Temperature : 32°F (0°C)
  • Network (RJ-45) : Yes
  • Remote Outlet Switching : Yes
  • Maximum Operating Temperature : 140°F (60°C)
  • Phase : Three Phase
  • Output Voltage : 240 V AC
  • Mount Type : Button Mount
  • Mount Type : Rack-mountable
  • Minimum Operating Humidity : 8%
  • Plug/Connector Type : NEMA L22-30P
  • Maximum Operating Humidity : 90%
  • Minimum Storage Temperature : -40°F (-40°C)
  • Receptacle Type : IEC 60320 C13
  • Rack Height : 0U
  • Maximum Storage Temperature : 185°F (85°C)
  • Receptacle Detail : 48 x IEC 60320 C13
  • Power Rating (Watt) : 17.30 kW
  • Input Current : 30 A
  • Height : 69"
  • Protection Type : Fuse
  • Protection Type : Circuit Breaker
  • Protection Type : Circuit Protection
  • Protection Type : Branch Circuit
  • Width : 3.3"
  • Locking Receptacles : P-Lock
  • Depth : 2.3"
  • Features : LED Display
  • Additional Info

    Additional Info

    SKU 17145STV4523Z-BF
    Weight 1.0000
    Is Featured N/A
    Manufacturer Server Technology, Inc
    Manufacturer Part Number STV-4523Z
    Width 3.3"
    Length 1
    Height 69"
    Product ID 17145STV4523Z
    UNSPSC N/A
    Other Part Number N/A
    Special Price N/A
