Tycon Power (TP-DCDC-4856G-VHP) 36-72VDC In, 56VDC 70W Passive POE Out DCDC - 72 V DC Input - 56 V DC, 1.25 A Output - 1 x Gigabit Ethernet Input Port(s) - 1 x Gigabit Ethernet Output Port(s) - 70 W

The TP-DCDC-4856G-VHP is a very high power DC to DC converter / passive POE inserter designed for Ubiquiti airFiber™ antennas and also various outdoor PTZ security cameras.

The DCDC converter supplies 70W passive POE power on all 8 Ethernet wires.

They have two isolated inputs for connecting 2 power sources, like a primary and backup power source. They have various protections for surge, short circuit and overload. The input and output are isolated.

Availability: Call or email

$153.75
$153.75

Fast shipping on all in-stock products

Quick turnaround on RFQs - email us today.

Buy from a certified veteran-owned small business (VOSB)

Questions? Call customer service at 503-208-8410.

Description

Details

Tycon Power (TP-DCDC-4856G-VHP) 36-72VDC In, 56VDC 70W Passive POE Out DCDC - 72 V DC Input - 56 V DC, 1.25 A Output - 1 x Gigabit Ethernet Input Port(s) - 1 x Gigabit Ethernet Output Port(s) - 70 W

OVERVIEW:

  • Limited Warranty : 1 Year
  • Protection Type : Over Voltage
  • Protection Type : Over Current
  • Protection Type : Short Circuit
  • Input Voltage : 72 V DC
  • Input Ports : 1 x Gigabit Ethernet
  • Compatibility :
    • Ubiquiti airFiber Antennas
    • Axis Q60 Series PTZ Cameras
  • Output Ports : 1 x Gigabit Ethernet
  • Certifications & Standards :
    • FCC Class B EN55022 Class B
    • UL1950
    • CSA 22.2
  • T?V
  • Maximum Output Voltage : 56 V DC
  • Form Factor : External
  • Environmentally Friendly : Yes
  • Height : 1.5"
  • Width : 3"
  • Depth : 4.9"
  • Maximum Output Current : 1.25 A
  • Maximum Output Power : 70 W
  • Additional Info

    Additional Info

    SKU 06063TPDCDC4856GVHP-BF
    Weight 1.0000
    Is Featured N/A
    Manufacturer Tycon Power Systems
    Manufacturer Part Number TP-DCDC-4856G-VHP
    Width 3"
    Length 1
    Height 1.5"
    Product ID 06063TPDCDC4856GVHP
    UNSPSC N/A
    Other Part Number N/A
    Special Price N/A
