ComNet Power Over Ethernet (PoE+) Midspan Injector For 10/100/1000T(X) - 120 V AC, 230 V AC Input - 56 V DC, 625 mA Output - 1 x 10/100/1000Base-T Input Port(s) - 1 x 10/100/1000Base-T Output Port(s) - 30 W - DIN Rail/Wall Mountable

The ComNet™ CNGE1IPS is an industrial power over Ethernet (PoE+) midspan injection module that injects 56 VDC at 0.625 amperes to any network cable. Operating power and 10/100/1000T(X) Ethernet data are easily combined on one cable, eliminating the need to install additional power outlets and electrical cabling. The CNGE1IPS is fully compliant with the requirements of IEEE 802.3at for Power Sourcing Equipment (PSE), and features auto detection of powered devices (PDs). Transmission distances of up to 330 feet (100 meters) are supported, and this injector supplies operating power for all PDs drawing a maximum of 30 watts. The unit provides AC line and powered device over-voltage and short circuit protection. Ideally suited to fiber optic, wireless, or other networks where it may be difficult to furnish operating power to the PDs, the CNGE1IPS is a true plug-and-play product requiring no user configuration or other set-up.

Availability: Call or email

$236.91
$236.91

Fast shipping on all in-stock products

Quick turnaround on RFQs - email us today.

Buy from a certified veteran-owned small business (VOSB)

Questions? Call customer service at 503-208-8410.

Description

Details

ComNet Power Over Ethernet (PoE+) Midspan Injector For 10/100/1000T(X) - 120 V AC, 230 V AC Input - 56 V DC, 625 mA Output - 1 x 10/100/1000Base-T Input Port(s) - 1 x 10/100/1000Base-T Output Port(s) - 30 W - DIN Rail/Wall Mountable

OVERVIEW:

  • Limited Warranty : 5 Year
  • Input Voltage : 230 V AC
  • Input Voltage : 120 V AC
  • Package Contents :
    • Power Over Ethernet (PoE+) Midspan Injector For 10/100/1000T(X)
    • Power Supply
    • DIN_Rail Mounting Adaptor Kit
  • Input Ports : 1 x 10/100/1000Base-T
  • Compatibility :

    ComNet Products:

    • NW1/NW2 (Industrially Hardened Point-to-Multipoint Wireless Ethernet Link)
    • NW7[E] (Environmentally Hardened High Throughput Wireless Ethernet Device)
    • NW8[E] (Environmentally Hardened Dual Radio Wireless Ethernet Device)
    • IP CCTV Cameras
    • Voice over IP (VoIP) Telephony Networks
    • Wireless LAN Access Points
    • IP Networks
  • Output Ports : 1 x 10/100/1000Base-T
  • Certifications & Standards :
    • UL 1950
    • CSA 22.2
    • FCC Class B
    • EN55022 Class B
    • CE
    • EN60950-1
    • IEEE 802.3
    • IEEE802.3u
    • IEEE802.3ab
    • IEEE802.3at
  • T?V
  • Maximum Output Voltage : 56 V DC
  • Form Factor : External
  • Environmentally Friendly : Yes
  • Mount Type : DIN Rail/Wall Mountable
  • Maximum Input Current : 750 mA
  • Height : 3"
  • Width : 4.9"
  • Depth : 1.5"
  • Environmental Compliance : Restriction of Hazardous Substances (RoHS)
  • Maximum Output Current : 625 mA
  • Maximum Output Power : 30 W
  • Additional Info

    Additional Info

    SKU 04938CNGE1IPS-BF
    Weight 1.0000
    Is Featured N/A
    Manufacturer ACRE
    Manufacturer Part Number CNGE1IPS
    Width 4.9"
    Length 1
    Height 3"
    Product ID 04938CNGE1IPS
    UNSPSC N/A
    Other Part Number N/A
    Special Price N/A
