ComNet CNGE1IPSXXAC PoE++ Injector - 120 V AC, 230 V AC Input - 57 V DC Output - RJ-45 Input Port(s) - RJ-45 Output Port(s) - 95 W

The ComNet CNGE1IPSXXAC series consists of industrial Power over Ethernet midspan injection modules that inject 50-57 VDC at to any network cable. Operating power and 10/100/1000TX Ethernet data are easily combined on one cable, eliminating the need to install additional power outlets and electrical cabling. The CNGE1IPS95 is fully compliant with the requirements of IEEE 802.3at for Power Sourcing Equipment (PSE), and features auto detection of powered devices (PDs). Transmission distances of up to 328 feet (100 meters) are supported, and this injector supplies operating power for PDs drawing a maximum of 75 and/or 95 watts (model dependent). Ideally suited to fiber optic, wireless, or other networks where it may be difficult to furnish operating power to the PDs, the CNGE1IPSXXAC series offers a true plug-and-play product requiring no user configuration or other set-up.

Availability: Call or email

$560.30
$560.30

Fast shipping on all in-stock products

Quick turnaround on RFQs - email us today.

Buy from a certified veteran-owned small business (VOSB)

Questions? Call customer service at 503-208-8410.

Description

Details

ComNet CNGE1IPSXXAC PoE++ Injector - 120 V AC, 230 V AC Input - 57 V DC Output - RJ-45 Input Port(s) - RJ-45 Output Port(s) - 95 W

OVERVIEW:

  • Limited Warranty : Lifetime
  • Protection Type : Surge Protection
  • Input Voltage : 230 V AC
  • Input Voltage : 120 V AC
  • Input Ports : RJ-45
  • Compatibility :

    Compatible Products:

    • IP CCTV cameras
    • Voice over IP (VoIP)
    • wireless LAN access points
  • Output Ports : RJ-45
  • Certifications & Standards :
    • IEEE 802.3at
    • IEEE802.3
    • IEEE802.3u
    • IEEE802.3ab
    • FCC Part 15 Subpart B Class A
    • CE EN 55022 Class A
    • cUL/UL
  • Maximum Output Voltage : 57 V DC
  • Form Factor : DIN Rail/Wall Mountable
  • Maximum Input Current : 2 A
  • Height : 8.4"
  • Width : 5.3"
  • Depth : 1.6"
  • Weight (Approximate) : 14.72 oz
  • Maximum Output Power : 95 W
  • Additional Info

    Additional Info

    SKU 04938CNGE1IPS95AC-BF
    Weight 14.7200
    Is Featured N/A
    Manufacturer ACRE
    Manufacturer Part Number CNGE1IPS95AC
    Width 5.3"
    Length 1
    Height 8.4"
    Product ID 04938CNGE1IPS95AC
    UNSPSC N/A
    Other Part Number N/A
    Special Price N/A
