Vertiv Geist Universal Rack PDU with Next Generation IMD| 32A-63A| 208V-415V| (18) U-Lock C13 and (12) U-Lock C19 Receptacles| 22kW| VP7UV0A0 - Redundant Power-Sharing Port | High-Contrast Display | Internal Orientation Sensor | Enhanced Security | Interc

The Vertiv Geist VP7UV0A0 is a vertical rack power distribution unit with a universal input that supports common AC power configurations. It has (18) U-Lock C13 outlets and (12) U-Lock C19 receptacles providing 22kW of power capacity. This unit can accommodate input power ranging from 32A-63A and 208V-415V in both single phase and three phase configurations. It helps simplify the rPDU procurement process since users can use a single model to work with different power sources. It is integrated with the Vertiv Geist Next Generation Interchangeable Monitoring Device (IMD). It has a 128x128 high-contrast LCD that displays the power usage. It features enhanced security with a secure boot that helps protect data and operations. It also has a redundant power-sharing port that connects two IMDs in the rack and provides backup power in case of power loss. The units are Dual Listed (UL/CE), TAA-Compliant, and individually tested for functionality and reliability.

More from the Manufacturer

Availability: Call or email

Regular Price: $3,636.32

Special Price $3,418.14

Regular Price: $3,636.32

Special Price $3,418.14

Fast shipping on all in-stock products

Quick turnaround on RFQs - email us today.

Buy from a certified veteran-owned small business (VOSB)

Questions? Call customer service at 503-208-8410.

Description

Details

Vertiv Geist Universal Rack PDU with Next Generation IMD| 32A-63A| 208V-415V| (18) U-Lock C13 and (12) U-Lock C19 Receptacles| 22kW| VP7UV0A0 - Redundant Power-Sharing Port | High-Contrast Display | Internal Orientation Sensor | Enhanced Security | Interchangeable Monitoring Device | Dual Listed (UL/CE) | TAA-Compliant | RoHS Certified | Hyperscale| 3-Year Warranty Which Extends to 5-Year Warranty if Registered Within 120 Days of Purchase

OVERVIEW:

  • Limited Warranty : 5 Year
  • PDU Type : Switched Outlet Monitored
  • Input Voltage : 208 V AC
  • Input Voltage : 240 V AC
  • Product Color : Black
  • Management :
  • DHCP
  • HTTP
  • HTTPS
  • IPv4
  • IPv6
  • LDAP
  • NTP
  • RADIUS
  • RSTP
  • SSH
  • SMTP
  • SNMP (v1/v2c/v3)
  • Syslog
  • TACACS+
  • Network (RJ-45) : Yes
  • Additional Warranty Information : 5-year limited warranty if registered within 120 days of purchase, otherwise warranty defaults to 3 years
  • Mounting Orientation : Vertical
  • Remote Outlet Switching : Yes
  • Phase : Single Phase/Three Phase
  • Mount Type : Rack-mountable
  • Energy Star : No
  • Plug/Connector Type : Universal Input
  • Country of Origin : United States
  • Plug/Connector Detail : 1 x Universal Input
  • TAA Compliant : Yes
  • Receptacle Type : U-Lock IEC 60320 C19
  • Receptacle Type : U-Lock IEC 60320 C13
  • Rack Height : 0U
  • Environmentally Friendly : Yes
  • Receptacle Detail : 12 x U-Lock IEC 60320 C19
  • Receptacle Detail : 18 x U-Lock IEC 60320 C13
  • Power Rating (Watt) : 22 kW
  • Input Current : 63 A
  • Protection Type : Overcurrent Protection
  • Width : 2"
  • Locking Receptacles : Ulock
  • Depth : 2.6"
  • Environmental Compliance : China Restriction of Hazardous Substances (China RoHS)
  • Length : 72"
  • Weight (Approximate) : 25 lb
  • Features : Touch Screen Display
  • Additional Info

    Additional Info

    SKU 04478VP7UV0A0-BF
    Weight 25.0000
    Is Featured N/A
    Manufacturer Vertiv
    Manufacturer Part Number VP7UV0A0
    Width 2"
    Length 72"
    Height 1
    Product ID 04478VP7UV0A0
    UNSPSC N/A
    Other Part Number N/A
    Special Price N/A
