Entry-Level Access Switch Series Delivers Unprecedented Performance and Features in Its Class
The RUCKUS ICX 7150 series of stackable switches delivers the performance, flexibility, and scalability required for enterprise access deployment, raising the bar with non-blocking performance and up to 8x10 GbE ports for uplinks or stacking. It offers seamless interoperability with RUCKUS wireless products to deliver unified wired and wireless network access. In addition, RUCKUS Multigigabit Ethernet technology offers bandwidth speeds needed to optimize performance of the latest generation high performance wireless access points and edge devices, over standard Ethernet cables.
Benefits
Stackability Simplifies Management
- Class-leading stacking scalability with up to 12 switches per stack
- Long-distance stacking up to 10 km using standard optics or cables 10 GbE Ports Optimize Network Performance ? Up to 8?10 GbE SFP+ ports for stacking or uplinks
Dual Power Supplies for High Availability
- Dual load-sharing, hot-swappable power supplies available on the Z-Series switch
Multigigabit Support Enables Next Generation Wireless Deployment
- Up to 16x 2.5 and 2x 2.5/5/10 GbE ports optimized for Wi-Fi 5 and 6 deployment
Class leading PoE Budget to Power Advanced Edge Devices
- PoE+/PoH/802.3bt budget (up to 1,480 watts)1
- Support advanced wireless APs and video surveillance equipment
Silent Operation for Deployment in the Work Environment
- Fanless design or fanless mode enables silent nondisruptive deployment anywhere
Advanced L3 Maximizes Flexibility
- OSPF, VRRP, PIM, PBR L3 features
Campus Fabric Reduces Cost of Operations, Increases Flexibility
- RUCKUS Campus Fabric delivers the benefits of a chassis with the flexibility of stackables
- Scales to over 1800 ports
Stacking Across the ICX 7150 Series
RUCKUS stacking technology makes it possible to stack up to twelve RUCKUS ICX 7150 switches into a single logical switch. This allows the RUCKUS ICX 7150 to deliver a class-leading 480 Gbps of aggregated stacking bandwidth and offer simple and robust expandability for future growth. Stacking is supported across the ICX 7150 series and all ICX 7150 models including the ICX 7150 compact switches and the ICX 7150- 48ZP can be mixed within the same stack. This stacked switch has only a single IP address that simplifies management and offers transparent forwarding across up to 600?1 GbE ports or up to 192?2.5 GbE ports, and up to 96?10 GbE ports. When new switches join the stack, they automatically inherit the stack's existing configuration file, enabling a plug-and-play network expansion.
