ComNet CTS24+2 Switch Chassis - 24 Ports - Manageable - 2 Layer Supported - Modular - 26 SFP Slots - 20 W Power Consumption - Twisted Pair, Optical Fiber - 1U - Rack-mountable - 5 Year Limited Warranty

The ComNet CTS24+2 is a managed layer-2 commercial grade Ethernet transport system and provides up to 24 ports of 10/100TX Ethernet and two ports of 10/100/1000TX or 1000FX transmission. The CTS24+2 series allows for ultimate flexibility in combining standard copper, optical, and extended distance Ethernet all in one rack mounted chassis configuration. Optional PoE allows the user to customize a solution to fit a specific application in a 1 RU rack space.

The system includes a chassis with optional PoE supplies of 400 or 720 Watts. Up to three 8 channel modules can be ordered to populate the system. These modules are offered in conventional CAT5/6 10/100 Mbps Ethernet, 100FX optical SFP, or CopperLine® Coax or UTP interfaces. The selected combination of chassis and modules are assembled at the factory to ensure your configuration is tested as a complete unit.

Features

  • Commercial Grade
  • IEEE802.3at PoE+ 30W (PoE models only)
  • Tagged VLAN (IEEE 802.1Q)
  • STP & RSTP supported
  • Fully configurable via web based GUI or USB CLI
  • IGMP v2/v3 (IGMP snooping support) for filtering multicast traffic
  • Gigabit combo uplinks
  • Modules capable of 8 ports each, up to a total of 24 configurable PoE-capable ports.
  • CopperLine rate management (10/100 Mbps)
  • Electric Port Supports Auto-negotiation for Full Duplex or Half Duplex Data Throughput

Availability: Call or email

$2,405.61
$2,405.61

Fast shipping on all in-stock products

Quick turnaround on RFQs - email us today.

Buy from a certified veteran-owned small business (VOSB)

Questions? Call customer service at 503-208-8410.

Description

Details

ComNet CTS24+2 Switch Chassis - 24 Ports - Manageable - 2 Layer Supported - Modular - 26 SFP Slots - 20 W Power Consumption - Twisted Pair, Optical Fiber - 1U - Rack-mountable - 5 Year Limited Warranty

OVERVIEW:

  • Limited Warranty : 5 Year
  • Manageable : Yes
  • Layer Supported : 2
  • Package Contents :
    • CTS24+2 Switch Chassis
    • Power Supply
  • Media Type Supported : Optical Fiber
  • Media Type Supported : Twisted Pair
  • Total Number of Network Ports : 24
  • Ethernet Technology : Gigabit Ethernet
  • Ethernet Technology : Fast Ethernet
  • Total Number of Expansion Slots : 26.0
  • Compatible Rack Unit : 1U
  • Environmentally Friendly : Yes
  • Network Technology : 1000Base-X
  • Network Technology : 100Base-FX
  • Expansion Slot Type : SFP (mini-GBIC)
  • Uplink Port : Yes
  • Power Source : Power Supply
  • Form Factor : Rack-mountable
  • Shared SFP Slot : Yes
  • Modular : Yes
  • Height : 1.8"
  • Number of SFP Slots : 26
  • Width : 17.1"
  • Port/Expansion Slot Details : 2 x Gigabit Ethernet Combo (Ethernet /SFP)
  • Port/Expansion Slot Details : 24 x Fast Ethernet Expansion Slot
  • Depth : 14.4"
  • Environmental Compliance : Waste Electrical and Electronic Equipment Directive (WEEE)
  • Environmental Compliance : Restriction of Hazardous Substances (RoHS)
  • Power Consumption : 20 W
  • Country of Origin : United States
  • Additional Info

    Additional Info

    SKU 04938CTS24+2SFP-BF
    Weight 1.0000
    Is Featured N/A
    Manufacturer ACRE
    Manufacturer Part Number CTS24+2SFP
    Width 17.1"
    Length 1
    Height 1.8"
    Product ID 04938CTS24+2SFP
    UNSPSC N/A
    Other Part Number N/A
    Special Price N/A
