The ComNet CNGE8MS/DIN is an 8-port Managed Ethernet Switch designed to reliably operate in harsh, environmentally challenging applications. It features eight (8) 10/100/1000BASE-T(X) ports. Exclusive to ComNet is X-Ring Pro, a feature that protects the network from interruptions or temporary malfunctions with fast recovery technology. Redundant DC inputs are included for uninterrupted operation in the event of a power supply failure. The electrical ports support the 10/100/1000Mbps Ethernet IEEE802.3 protocol, and auto-negotiating and auto-MDi/MDiX features are provided. These network-managed layer 2 switches are electrically compatible with any IEEE802.3 compliant Ethernet device.
Features
- STP/RSTP/MSTP supported
- Supports Link Layer Discovery Protocol (LLDP)
- Port lock to prevent access from unauthorized MAC address
- SNMP V1/V2c/V3 for secure network management
- Rigid aluminum housing
- Designed for wall or DIN rail mount installations
- IGMP v1/v2 (IGMP snooping support) for filtering multicast traffic & Port Trunking for ease of bandwidth management
- Event notification through Syslog, RMON, SNMP trap, and Relay Output
- IPV6 internet protocol (latest version)
- Provides SSH/SSL protocol for enhanced network security
- Fastest Redundant Ethernet Ring: ComNet X-Ring Pro. Recovery time < 30 ms, with > 250 switches within the ring
- Designed to meet full compliance with the environmental requirements (ambient operating temperature, mechanical shock, vibration, humidity with condensation, high-line/low-line voltage conditions, and transient voltage protection) of NEMA TS-1/TS-2 and the Caltrans Specification for Traffic Signal Control Equipment.
- Electric Port Supports Auto-negotiation for Full Duplex or Half Duplex Data Throughput
- Web-based and Telnet configuration with support for network monitoring through ComNet eVision utility
Applications
- ITS Traffic Signalization & Surveillance
- Industrial and Factory Automation
- Integrated IP-Video and Data Transmission Networks
- Industrial Security Access Control Systems
- Incident Detection Networks
