Advantech EKI-7708G-4FPI Ethernet Switch - 4 Ports - Manageable - Gigabit Ethernet - 10/100/1000Base-T - 2 Layer Supported - Modular - 4 SFP Slots - Twisted Pair, Optical Fiber - Wall Mountable, DIN Rail Mountable - 5 Year Limited Warranty

EKI-7708G-4FP/4FPI supports 4 Gigabit IEEE 802.3 af/at PoE / PoE ports and 4 SFP (mini-GBIC) ports. They can provide up to 30 watts per port to fulfill high power consumption PD (Power Device) requirements. They are embedded with Advantech's IXM function, which can benefit users for fast deployment and can dramatically save engineers time and cost. The EKI-7708G series also supports NMS to help IT managers with networking maintenance and failure prevention. Finally, the EKI-7708G series is equipped with X-Ring Pro which can achieve ultra high speed recovery time of less than 20 ms to ensure network stability. The switch also features a wide -40° to 75°C operating temperature (EKI-7708G-4FPI) and NEMA TS2 rating, making the switch an ideal solution for use in traffic applications. EKI-7708G-4FP/4FPI has successfully passed the EN50121-4 European railway standard requirements for emissions and railway platform and trackside deployment.

Availability: Call or email

$1,021.00
$1,021.00

Fast shipping on all in-stock products

Quick turnaround on RFQs - email us today.

Buy from a certified veteran-owned small business (VOSB)

Questions? Call customer service at 503-208-8410.

Description

Details

Advantech EKI-7708G-4FPI Ethernet Switch - 4 Ports - Manageable - Gigabit Ethernet - 10/100/1000Base-T - 2 Layer Supported - Modular - 4 SFP Slots - Twisted Pair, Optical Fiber - Wall Mountable, DIN Rail Mountable - 5 Year Limited Warranty

OVERVIEW:

  • Limited Warranty : 5 Year
  • Manageable : Yes
  • Layer Supported : 2
  • Media Type Supported : Optical Fiber
  • Media Type Supported : Twisted Pair
  • Total Number of Network Ports : 4
  • Ethernet Technology : Gigabit Ethernet
  • Total Number of Expansion Slots : 4.0
  • Environmentally Friendly : Yes
  • Network Technology : 1000Base-X
  • Network Technology : 10/100/1000Base-T
  • Expansion Slot Type : SFP (mini-GBIC)
  • Form Factor : DIN Rail Mountable
  • Form Factor : Wall Mountable
  • Modular : Yes
  • Height : 6"
  • Number of SFP Slots : 4
  • Width : 2.9"
  • Port/Expansion Slot Details : 4 x Gigabit Ethernet Expansion Slot
  • Port/Expansion Slot Details : 4 x Gigabit Ethernet PoE+
  • Depth : 4.1"
  • Environmental Compliance : Restriction of Hazardous Substances (RoHS)
  • Country of Origin : Taiwan
  • Weight (Approximate) : 2.43 lb
  • Additional Info

    Additional Info

    SKU 01074EKI7708G4FPIAE-BF
    Weight 2.4300
    Is Featured N/A
    Manufacturer Advantech Co., Ltd
    Manufacturer Part Number EKI-7708G-4FPI-AE
    Width 2.9"
    Length 1
    Height 6"
    Product ID 01074EKI7708G4FPIAE
    UNSPSC N/A
    Other Part Number N/A
    Special Price N/A
