Mellanox QSFP28 Module - For Data Networking, Optical Network - 1 x LC Duplex 100Gbase-DR/DR1 Network - Optical Fiber - Single-mode - 100 Gigabit Ethernet - 100GBase-DR, 100GBase-DR1 - 100 Gbit/s - 0.50 km Maximum Distance - Hot-pluggable

Introduction

NVIDIA® MMS1V70-CM transceiver is a single mode 1-lane (DR1), QSFP28 optical transceiver, designed for use in 100 Gigabit Ethernet (GbE) links on up to 500m of single mode fiber.

The transceiver converts 4 input channels of 25Gb/s NRZ electrical data to a single optical channel of 100Gb/s PAM4 optical signals over a single fiber, using a nominal wavelength of 1310nm, and vice versa for the receive path. The MMS1V70-CM main application is to converge between legacy 100GbE NRZ systems and the emerging 400GbE PAM4 systems. Four different MMS1V70-CM transceivers can be connected to a single 400GbE QSFP-DD MMS1V00-WM DR4 transceiver over a single mode splitter cable.

It is compliant with the QSFP28 MSA, IEEE 802.3bm CAUI-4. Digital diagnostic functions are available via the I2C interface, as specified by the QSFP28 MSA.

Rigorous production testing ensures the best out-of-the-box installation experience, performance, and durability.
