Black Box DKM Compact KVM Matrix Switch - Redundant Power, CATx, 8-Port - 7 Computer(s) - 1 Local User(s) - 47 Hz, 63 Hz - 10 x Network (RJ-45) - Rack-mountable, Desktop - TAA Compliant

  • The DKM Matrix switch enables switching between computers and remote consoles.
  • The DKM Compact switch is available in CATx and Fiber and in port sizes of 8, 16, 32, 48, 64 and 80.
  • The DKM 64 and 80 port switches offer hybrid interfaces that support both CATx and Fiber.
  • CATx endpoints can be extended up to 400 feet (122 m) and Fiber endpoints can be extended up to 6.2 miles (10 km).
  • Each port on the DKM is agnostic and can support a transmitter or receiver.
  • The DKM features instantaneous switching between sources using the same video resolution.
  • Users can interact with this KVM switch via hotkeys, OSD, eternal Java Utility, or an API interface.
  • The DKM can easily be cascaded to support future expansion in the event that every port is in use.
  • The DKM solution features transmitter and receiver endpoint options that can support DisplayPort, DVI-D, DVI-I, HDMI, VGA, USB HID, USB 2.0, Analog Audio, Digital Audio, RS232, and RS422.
  • Black Box can also help you support legacy interfaces such as Component, Composite, S-Video, RGB Video, even with PS/2 keyboards and mice.
  • The DKM transmitters and receivers support CATx or single-mode or Multi-mode Fiber which interfaces with the DKM FX KVM Switch.

Availability: Call or email

$3,368.03
$3,368.03
Black Box Corporation

Fast shipping on all in-stock products

Quick turnaround on RFQs - email us today.

Buy from a certified veteran-owned small business (VOSB)

Questions? Call customer service at 503-208-8410.

Description

Details

Black Box DKM Compact KVM Matrix Switch - Redundant Power, CATx, 8-Port - 7 Computer(s) - 1 Local User(s) - 47 Hz, 63 Hz - 10 x Network (RJ-45) - Rack-mountable, Desktop - TAA Compliant

OVERVIEW:

  • Limited Warranty : 2 Year
  • Input Voltage Range : 88V AC to 264V AC
  • Form Factor : Desktop
  • Form Factor : Rack-mountable
  • Package Contents :
    • DKM Compact KVM Matrix Switch - Redundant Power, CATx, 8-Port
    • 1 x US Power Cord
    • 1 x RJ45/DB9 Adapter
    • 4 x Rubber Feet
    • User Manual
    • 1 x 19" Rack Mount
  • Network (RJ-45) : Yes
  • Frequency : 63 Hz
  • Frequency : 47 Hz
  • Number of Computers Supported : 7
  • Height : 1.7"
  • Number of Local Users Supported : 1
  • Width : 8.8"
  • Environmentally Friendly : Yes
  • Depth : 5.8"
  • Weight (Approximate) : 4.06 lb
  • Maximum Operating Distance : 400 ft
  • Country of Origin : Germany
  • TAA Compliant : Yes
  • Number of Network (RJ-45) Ports : 10
  • Additional Info

    Additional Info

    SKU 01312ACXC8-BF
    Weight 4.0600
    Is Featured N/A
    Manufacturer Black Box Corporation
    Manufacturer Part Number ACXC8
    Width 8.8"
    Length 1
    Height 1.7"
    Product ID 01312ACXC8
    UNSPSC N/A
    Other Part Number N/A
    Special Price N/A
