NVT Phybridge UTP Video Transmitter +12VDC Converter - 3280.84 ft RangeNetwork (RJ-45) - Twisted Pair - Category 5

Features:

  • Extended distance camera power and video routed through UTP and RJ45
  • Supports 12VDC cameras with onboard regulated power
  • Use with NVT's PVD™ Power Supply Hubs and Cable Integrators
  • Up to 3,000ft (1km) with a NVT DigitalEQTM Hub or active receiver, (see Power Distance Chart)
  • Up to 1,500ft (460m) with a NVT StubEQTM Hub
  • Frequency response DC to 10MHz (see Recommended Distance Chart)
  • Up to 750ft (225m) with NVT's Passive Receiver Hubs (see Power Distance Chart)
  • Exceptional interference rejection
  • Built-in transient protection
  • Limited lifetime warranty
The NV-226J-PV Video Transmitter +12VDC Converter is a passive (non-amplified) video transmitter combined with a 24VACto-12VDC converter. Designed to fit on the back of a fixed 12 VDC camera, this unit is architected to convert 24VAC power from the control room, while delivering real-time baseband (composite) video at extended distances, all over one 4-pair UTP cable.

The unparalleled interference rejection and low emissions of the NV-226J-PV allows video and lowvoltage power to coexist within the same 4-pair cable, using structured (EIA 568B) wiring practices. It is recommended that the 24VAC not share the same jacketed wire bundle with telecom or datacom signals.

The NV-226J-PV carries a limited lifetime warranty, is UL and cUL listed, and is CE, WEEE, and RoHs compliant.

Availability: Call or email

$95.15
$95.15

Fast shipping on all in-stock products

Quick turnaround on RFQs - email us today.

Buy from a certified veteran-owned small business (VOSB)

Questions? Call customer service at 503-208-8410.

Description

Details

NVT Phybridge UTP Video Transmitter +12VDC Converter - 3280.84 ft RangeNetwork (RJ-45) - Twisted Pair - Category 5

OVERVIEW:

  • Limited Warranty : Lifetime
  • Connectivity Technology : Wired
  • Media Type Supported : Twisted Pair
  • Network (RJ-45) : Yes
  • Twisted Pair Cable Standard : Category 5
  • Transmitter Height : 2.25"
  • Maximum Operating Distance : 3280.84 ft
  • Transmitter Width : 1.52"
  • Transmitter Depth : 0.81"
  • Environmentally Friendly : Yes
  • Transmitter Weight (Approximate) : 1.76 oz
  • Environmental Compliance : Restriction of Hazardous Substances (RoHS)
  • Environmental Compliance : Waste Electrical and Electronic Equipment Directive (WEEE)
  • Additional Info

    Additional Info

    SKU 05791NV226JPV-BF
    Weight 1.0000
    Is Featured N/A
    Manufacturer Phybridge, Inc
    Manufacturer Part Number NV-226J-PV
    Width 1
    Length 1
    Height 1
