Advantech EKI-1224 4-Port Modbus Gateway - Twisted Pair - 2 x Network (RJ-45) - 4 x Serial Port - 10/100Base-TX - Fast Ethernet - DIN Rail Mountable, Wall Mountable

The EKI-1200 series Modbus gateways are bi-directional gateways for integrating new and existing Modbus/RTU and Modbus/ASCII serial devices to newer TCP/IP networked-based devices. The EKI-1221/1222/1224 feature two independent Ethernet ports and MAC addresses to provide redundancy and reliability. They provide a simple and cost-effective way to bring remote management and data accessibility to thousands of devices that cannot otherwise connect to a network. The EKI-1221/1222/1224 allow users to select master or slave operation mode for each serial port. In addition to allowing an Ethernet master to control serial slaves, they also allow serial masters to control Ethernet slaves.

Availability: Call or email

$605.73
$605.73

Fast shipping on all in-stock products

Quick turnaround on RFQs - email us today.

Buy from a certified veteran-owned small business (VOSB)

Questions? Call customer service at 503-208-8410.

Description

Details

Advantech EKI-1224 4-Port Modbus Gateway - Twisted Pair - 2 x Network (RJ-45) - 4 x Serial Port - 10/100Base-TX - Fast Ethernet - DIN Rail Mountable, Wall Mountable

OVERVIEW:

  • Ethernet Technology : Fast Ethernet
  • Media Type Supported : Twisted Pair
  • Network (RJ-45) : Yes
  • Connectivity Technology : Wired
  • Input Voltage : 48 V DC
  • Network Standard : 10/100Base-TX
  • Input Voltage Range : 12VDC - 48VDC
  • Form Factor : Wall Mountable
  • Form Factor : DIN Rail Mountable
  • Power Consumption : 4.10 W
  • Plug/Connector Type : Terminal Block
  • Height : 5.5"
  • Serial Port : Yes
  • Width : 1.9"
  • Depth : 3.7"
  • Weight (Approximate) : 1.22 lb
  • Number of Network (RJ-45) Ports : 2
  • Number of Serial Ports : 4
  • Additional Info

    Additional Info

    SKU 01074EKI1224CE-BF
    Weight 1.2200
    Is Featured N/A
    Manufacturer Advantech Co., Ltd
    Manufacturer Part Number EKI-1224-CE
    Width 1.9"
    Length 1
    Height 5.5"
    Product ID 01074EKI1224CE
    UNSPSC N/A
    Other Part Number N/A
    Special Price N/A
