Cisco C220 M5 1U Rack Server - 1 Xeon Silver 4210R 2.40 GHz - 32 GB RAM - 1.92 TB SSD - (4 x 480GB) SSD Configuration - 12Gb/s SAS Controller - Intel C621 Chip - 2 Processor Support - 3 TB RAM Support - DDR4 SDRAM - 1, 10 RAID Levels - Pilot 4 Up to 16 MB

The UCS C220 M5 SFF server extends the capabilities of Cisco's Unified Computing System portfolio in a 1U form factor with the 2nd Generation Intel® Xeon® Scalable Processors, DDR4-3200MHz memory, and the new 512GB Intel® Optane™ Persistent Memory Modules (PMem). With this combination of features, up to 9 TB of memory is possible (using 12 x 256 GB DDR4 DIMMs and 12 x 512 GB PMem), two 2 PCI Express (PCIe) 3.0 slots, and up to 10 SAS/SATA hard disk drives (HDDs) or solid state drives (SSDs). The C220 M5 SFF server also includes one dedicated internal slot for a 12G SAS storage controller card.

The C220 M5 server includes one dedicated internal modular LAN on motherboard (mLOM) connector for installation of a Cisco Virtual Interface Card (VIC) or third-party network interface card (NIC), without consuming a PCI slot, in addition to 2 x 10Gbase-T Intel x550 embedded (on the motherboard) LOM ports.

The Cisco UCS C220 M5 server can be used standalone, or as part of the Cisco Unified Computing System, which unifies computing, networking, management, virtualization, and storage access into a single integrated architecture, enabling end-to-end server visibility, management, and control in both bare metal and virtualized environments.

Availability: Call or email

$5,611.91
$5,611.91
Cisco Systems, Inc

Fast shipping on all in-stock products

Quick turnaround on RFQs - email us today.

Buy from a certified veteran-owned small business (VOSB)

Questions? Call customer service at 503-208-8410.

Description

Details

Cisco C220 M5 1U Rack Server - 1 Xeon Silver 4210R 2.40 GHz - 32 GB RAM - 1.92 TB SSD - (4 x 480GB) SSD Configuration - 12Gb/s SAS Controller - Intel C621 Chip - 2 Processor Support - 3 TB RAM Support - DDR4 SDRAM - 1, 10 RAID Levels - Pilot 4 Up to 16 MB Graphic Card - 10 Gigabit Ethernet - 10 x SFF Bay(s) - Hot Swappable Bays - 2 x 1050 W - Redundant Power Supply - Intel Optane Memory Ready

OVERVIEW:

  • Operating System Supported : Windows Server 2019 Datacenter
  • Operating System Supported : Windows Server 2019 Standard
  • Chipset Manufacturer : Intel
  • Number of Processors Supported : 2
  • Limited Warranty : 3 Year
  • Input Voltage : 230 V AC
  • Input Voltage : 120 V AC
  • Form Factor : Rack
  • Ethernet Technology : 10 Gigabit Ethernet
  • Standard Memory : 32 GB
  • Number of Total Expansion Bays : 10
  • Controller Type : 12Gb/s SAS
  • Chipset Model : C621
  • Number of Processors Installed : 1
  • Additional Warranty Information :
    • Three-year parts coverage.
    • Next business day (NBD) parts replacement eight hours a day, five days a week.
    • 90-day software warranty on media.
  • Number of Power Supplies Supported : 2
  • Rack Height : 1U
  • Maximum Memory Supported : 3 TB
  • Number of Power Supplies Installed : 2
  • Height : 1.7"
  • Memory Technology : DDR4 SDRAM
  • Graphics Controller Model : Pilot 4
  • RAID Supported : Yes
  • Total Number of USB Ports : 3
  • Processor Type : Xeon Silver
  • Width : 19"
  • Memory Clock Speed : 2.93 GHz
  • RAID Levels : 1, 10
  • Processor Generation : 2nd Gen
  • Maximum Power Supply Wattage : 1050 W
  • Depth : 31"
  • Number of Internal 2.5" Bays : 10
  • Graphics Memory Capacity : 16 MB
  • Number of USB 3.0 Ports : 2.0
  • Processor Model : 4210R
  • Number of Solid State Drives : 4
  • Redundant Power Supply : Yes
  • Weight (Approximate) : 59.97 lb
  • Processor Core : Deca-core (10 Core)
  • Total Solid State Drive Capacity : 1.92 TB
  • Hot Swappable Power Supply : Yes
  • Number of Occupied Memory Slots : 2.0
  • Number of SFF Bays : 10
  • Processor Speed : 2.40 GHz
  • Solid State Drive Interface : 6Gb/s SAS
  • Intel Optane Memory Ready : Yes
  • Network (RJ-45) : Yes
  • Hot Swappable Bays : Yes
  • Number of Network (RJ-45) Ports : 2
  • Error Checking : ECC
  • Total Number of Expansion Slots : 2.0
  • VGA : Yes
  • Signal Processing : Registered (Buffered)
  • Cache : 13.75 MB
  • Remote Management : Yes
  • Remote Management Controller : Baseboard Management Controller (BMC)
  • PCI Express Details : 1 (total) x PCIe 3.0 x24 - half-length, half-height (x16 mode / NCSI support);1 (total) x PCIe 3.0 x24 - three-quarter-length, full-height (x16 mode)
  • Additional Info

    Additional Info

    SKU 01468CVCNTRM5S3-BF
    Weight 59.9700
    Is Featured N/A
    Manufacturer Cisco Systems, Inc
    Manufacturer Part Number CV-CNTR-M5S3
    Width 19"
    Length 1
    Height 1.7"
    Product ID 01468CVCNTRM5S3
    UNSPSC N/A
    Other Part Number N/A
    Special Price N/A
