This Active Fiber Optic Cable contains an active chip to process and distribute the data signal which will work with most equipment. As with any active cables, in some cases, there can be performance or compatibility challenges with certain laptops, PCs, cameras or other USB devices depending on a variety of system conditions. Please contact our support department if you experience any of these type of issues.
This cable features a uni-directional design which requires the cable to be installed in the correct direction. One USB-C connector is marked "Source" and the other USB-C connector is marked "End" to ensure that the source and the destination USB device are properly connected.
The cable may not be compatible if the USB device only supports DP signal over four lanes.
Being a Fiber Optic cable, it must be handled with extra care compared to a copper cable during installation as extreme force and/or excessive or sharp bends could potentially damage or break the fiber optic cable inside.
Comprehensive's Pro AV/IT USB 10G 4K AV Active Optical Plenum Cables are bus powered and can extend the distance of USB connectivity with consistent and reliable signal performance. This AOC cable adopted the USB 3.2 Gen 2 technology and supports USB SuperSpeed 10Gbps data transmission, 4K AV (via DisplayPort Alt Mode) and power delivery 60 watts up to 32.8 ft lengths. These active optical extended cables are plenum rated for commercial installing of safe in-wall applications. This cable meets all bandwidth requirements of USB 3.2 Gen II and is backward compatible to USB 3.1, 3.0 & 2.0 peripherals.
Designed for U.C.C., Video Conferencing, Remote Work and Learning Applications
These Pro AV/IT Active Optical Plenum cables were specifically designed for today's business and education installations including U.C.C., Video Conferencing, Remote Work and Learning applications. It extends USB webcams, PTZ cameras, keyboards, mice, USB Hubs, USB microphones, external drives, flash sticks, VR headsets, printers, scanners and other digital devices.
Supports 4K AV & 60W Power Delivery
This Pro AV/IT Active Optical Plenum Type C to C cable is featured to support 4K60 video (via DP Alt Mode) and simultaneously delivers power charging up to 60 Watts.
Active Chipset Ensure End to End Signal Performance
With integrated chipsets, Pro AV/IT USB 10G Active Optical Plenum Cables ensure up to SuperSpeed 10G performance at longer lengths up to 33ft.
Thin, Flexible Design Makes for Easy Installation
This low-profile USB 3.2 Type-C Gen 2 AOC cable is flexible yet built to last, with durable premium construction, molded strain relief and high quality Shielded Twisted Pair (STP) construction, helping to prevent electro-magnetic interference and ensuring reliable data communication.
Compatible With Most Operating Systems
Supports all major operating systems including Windows®, MacOS®.
Plenum Rated (CMP) Cable Jacket
Comprehensive's USB 3.2 10G 4K AV extended cable is Plenum (CMP) rated, which is suitable for commercial installations.
